DIAMOND 2.31

Innovations and Extensions in ECU Programming Solutions

Diamond, an advanced solution for programming vehicle ECUs, introduces version 2.31.0.0, offering a series of updates and solutions for various vehicle ECUs.

GM Bosch T93 models , allowing access to the TCU’s Internal Flash memory without the application of patches that could void the vehicle warranty . It is possible to process shifting parameters or remove error codes from the Bosch T93 gearbox control unit installed on General Motors group vehicles . Additionally, Diamond expands Bench mode support for 2021 Ford Bosch EDC17C70 engine ECUs , further improving the range of supported vehicles.

Diamond version 2.31.0.0 also introduces new Bench solutions for Denso Gen4 engine ECUs , allowing processing of engine parameters without having to open the unit , with a focus on Mazda and Subaru vehicles with Skyactiv -G petrol engines . The new V2 interface simplifies the search for accessories for connection to ECUs and TCUs.

Boot mode programming of Delphi engine ECUs on heavy vehicles , as well as on Kia , Hyundai, Mahindra , Volkswagen, Seat, Skoda and Great Wall vehicles . These protocols allow reading and writing of Flash and EEPROM memories, with the possibility of resetting the ECU in case of writing errors in OBD .

Diamond also offers a solution for the processing of Mercedes MCM and ACM control units , with a focus on various Mercedes trucks and buses. These protocols allow you to work with the ECUs without applying programming patches, keeping the vehicle warranty valid .

Finally, Diamond version 2.31.0.0 features Full and Bench OBD solutions for Continental ACM2.1 and ACM2.2 AdBlue ECUs , eliminating the need to open the unit and without risk to your vehicle’s warranty .

Additionally, Diamond adds support for the Continental M3C model engine ECU, allowing Bench mode programming of various vehicles, including Ducati Hypermotard 1100, KTM EXC and Kymco AK . These solutions offer broad support for vehicles of different makes and models, making Diamond a versatile tool for ECU programming.

New Protocols Added TCU

New AdBlue Protocols Added

1 D1
1 D2
1 D3
1 D4
1 D5
MCM2 D3.1
MCM2 D3.2
1 D1
1 D2
1 D3 (also password protected)
1 D4
2 D2

New Protocols Added ECU

M3C
Delphi DCM2.7AP
Delphi DCM3.7 VAG
Delphi DCM7.1AP
Delphi DCM7.24
Denso GEN4

Vehicles added to the Diamond list

Cadillac CT6 2.0L Turbo 240PS
Chevrolet Camaro ZL1 6.2L V8 450PS
Chevrolet 3500 T1XX 6.6L V8 Turbo 440PS
GMC Denali L8T 6.6L V8 400PS
Ford Tourneo JU2 1.5L 75PS
Ford Transit Courier 1.5L 75PS
Mazda CX-3 1.5L Skyactiv -G 115PS
Mazda CX-5 2.0L Skyactiv -G 190PS
Mazda CX-8 2.5L Skyactiv -G 190PS
Subaru Crosstrek 2.0L FB20D 150PS
Hyundai i20 1.5L CRDi 100PS
Kia Seltos 1.5L CRDi 115PS
JCB Telehandler 4.4L 75PS
Landini Tractors Rex3 2.5L 55PS
Mahindra Xuv 1.5L 115PS
VW Polo 1.2 TDI 75Ps
Mercedes Truck Actros 1851 12.8L OM471LA 510HP
Mercedes Bus Citaro C2 10.7L OM470 394HP
Mercedes Bus Tourismo RHD 12.8L OM471LA 428HP
Setra S515 HDH 12.8L OM471LA 470HP
Freightliner Cascadia DD15 14.8L Detroit DD15 530HP
Arctic Cat Alterra AVTS 433cc
Can- Am Outlander ATV 650cc 59PS
Ducati Hypermotard 1100cc 85PS
Ducati Monster 700cc 76PS
KTM EXC 250cc 20HP
Kymco Maxxer 450cc 30HP
TBG Blade 1000cc 89HP
And so on…

Functions and timing

( Bench ) – T93

GM Bosch T93 SPC58 Read/Write/Checksum Calculation Internal Flash

Reading time : ~1 minute
Writing time : ~40 seconds

( Bench ) – ACM

Mercedes Trucks /Bus Continental ACM2.1 D1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental ACM2.1 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental ACM2.1 D3 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental ACM2.1 D3 (PW protected ) TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental ACM2.1 D4 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental ACM2.2 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Reading time : ~ 1.30 minutes
Writing time : ~ 2 minutes

( Bench – Boot ) MCM

Mercedes Trucks /Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
Mercedes Trucks /Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Reading time : ~ 1.30 minutes
Writing time : ~ 2 minutes

( Boot ) – DCM

Mahindra Delphi DCM2.7AP MPC5642 Read/Write/Checksum Calculation Internal Flash
JCB Delphi DCM2.7AP MPC5643 / MPC5644 Read/Write/Checksum Calculation Internal Flash

Reading time : ~1.40 minutes
Writing time : ~1.20 minutes

VAG Delphi DCM3.7 SH72513 Read Full Backup, Write Recovery

Reading time : ~15 seconds
Writing time : ~5 seconds

All Delphi DCM7.1AP TC277 Read/Write/Checksum Calculation Internal Flash, Read/Write/Checksum Calculation Internal EEPROM, Full Backup
JCB Delphi DCM7.24 TC277 Read/Write/Checksum Calculation Internal Flash, Read/Write/Checksum Calculation Internal EEPROM, Full Backup
JCB Delphi DCM7.24 TC297 Read/Write/Checksum Calculation Internal Flash, Read/Write/Checksum Calculation Internal EEPROM, Full Backup

Reading time : ~1.20 minutes
Writing time : ~20 seconds

( Bench ) – GEN4

Mazda Denso Gen4 MPC5746R ( Read /Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup
Subaru Denso Gen4 MPC5746R Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup

Reading time : ~1.30 minutes
Writing time : ~45 seconds

BUGFIX

Added new CRC type for VAG Continental Simos8.6
Added new type of CRC for Suzuki Denso SH7055
Added support for the second type of Mercedes Bosch MED17.7.5 in OBD mode
Fixed identification error for Saab Bosch EDC17CP21 in Bench mode
Fixed misidentification for Porsche Continental SDI21.3
Added new type of CRC for VAG Bosch MG1CS011
Added new CRC type for VAG Continental Simos8.2
Added new type of CRC for Land Rover Denso
Added new type of CRC for Ford Delphi MPC555
Porsche Continental SDIx in OBD mode – fixed issue requiring throttle reset
BMW Exx Series in OBD mode – fixed writing issue causing hang in OBD for some software versions
Added new type of CRC for FIAT GPEC2
Added new CRC type for Kefico CPEGD2.20.4
Added new type of CRC for Marelli MM10JA
