Diamond Bench Solution for MD1CP007 and DC4 Gen2
Diamond version 2.37.0.0 is ready
A new protocol for Land Rover brand vehicles and second generation Getrag DC4 automatic transmissions is now available on Diamond: with the latest software update, you will be able to program MD1CP007 engine ECUs and Getrag DC4 Gen2 gearbox ECUs in Bench mode.
Connect Diamond to the ECU or TCU connector to access the entire contents of the Internal Flash and Internal EEPROM memories and start your work: you will be able to optimize the performance of vehicles such as Defender and Range Rover or unleash the potential of the TCUs of Renault brand vehicles , Dacia and Smart equipped with Getrag DC4 Gen2 control units.
Here are some of the supported vehicles:
- Land Rover Defender L663 3.0L MHEV 203PS Hybrid
- Land Rover Defender L663 3.0L MHEV 304PS Hybrid
- Land Rover Range Rover L460 3.0L MHEV 253PS Hybrid
- Land Rover Range Rover L460 3.0L MHEV 304PS Hybrid
- Dacia Duster II 1.3L TCe 150PS
- Renault Megane IV 1.5L Blue dCi 115PS
- Renault Twingo III 0.9L TCe 90PS
- Smart Forfour W453 0.9L Turbo 90PS
- Smart Forfour W453 1.0L 70PS
New protocols added ( Bench )
- JLR Bosch MD1CP007 TC298 Read/Write/ Map checksum , Read/Write Internal EEPROM
Reading time : ~ 1 minute and 30 seconds
Writing time : ~ 1 minute
- All Getrag DC4 Gen2 TC1782F Read/Write/ Checksum Internal Flash, Read/Write Internal EEPROM, Read/Write Full Backup
Reading time : ~1 minute
Writing time : ~40 seconds
The CRC fixes are:
- Added new CRC type for PSA Continental SID80x
- Added new type of CRC for VAG Bosch MD1CS004
- Added new type of CRC for FCA Marelli MM10JA
- Added new CRC type for Mercedes Continental ACM2.1 D3
- Added new CRC type for VAG Continental Simos 7.1
- Added new type of CRC for Mazda Melco E6T
- Correction of CRC calculation for some versions of Marelli TCU
- Fixed CRC calculation for some Toyota Denso Gen3
